Specification : |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
Parameters |
|
|
|
Range |
|
|
|
|
|
|
| |
▪ |
DO Range |
|
|
|
0.00 to 99.99 ppm |
|
|
|
|
|
|
|
|
| |
|
Resolution |
|
|
|
0.01 ppm |
|
|
|
|
|
|
|
|
|
| |
|
Accuracy |
|
|
|
|
|
(0.00~50.00)ppm,±0.10ppm |
|
|
|
|
|
| |
|
Calibration Points |
|
|
Air-saturated water or zero point |
|
|
|
|
| |
|
Sensor Type |
|
|
|
Polarographic |
|
|
|
|
|
|
|
|
|
|
|
| |
▪ |
DO Sarturation |
|
|
(0.0 to 600.0)% |
|
|
|
|
|
|
|
|
|
|
|
| |
|
Resolution/Accuracy |
|
0.1% / ±2.0% |
|
|
|
|
|
|
|
|
|
| |
▪ |
Temperature |
|
|
|
-10 to 135 ºC |
|
|
|
|
|
|
|
|
|
| |
▪ |
Reading Mode |
|
|
Auto Read (Fast, Medium, Slow), Timed, Continuous |
|
| |
|
Reading prompts |
|
|
Reading, Stable, Locked |
|
|
|
|
|
|
| |
|
Temp. Compensation |
|
ATC, MTC |
|
|
|
|
|
|
|
|
|
|
| |
▪ |
Data Storage |
|
|
|
1000 Groups |
|
|
|
|
|
|
|
|
|
| |
▪ |
Inputs DO electrode |
|
4-pin aviation connector |
|
|
|
|
|
|
| |
▪ |
Display |
|
|
|
|
LCD display Backlight |
|
|
|
|
|
|
|
| |
|
Auto Shutdown |
|
|
1~60 min, off |
|
|
|
|
|
|
|
|
|
| |
|
IP Rating |
|
|
|
IP54 |
|
|
|
|
|
|
|
|
|
|
| |
▪ |
Output USB |
|
|
|
USB 2.0 flash memory device, PC, Scanner |
|
|
|
| |
|
|
|
|
|
|
|
RS 232 to Printer, auto-sampler |
|
|
|
|
|
| |
▪ |
Power |
|
|
|
|
AC Adapter 240V input DC9V output |
|
|
|
|
| |
▪ |
Dimensions/Weight |
|
220 x 195 x 68mm/950 gr |
|
|
|
|
|
|
| |
▪ |
Complete Unit |
|
|
Zero oxygen calibration solution, DO Electrolyte, |
|
| |
|
|
|
|
|
|
|
3pcs electrode membrane cover, Electrode Stand |
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
