Display |
: |
10" Colour touchscreen graphical user interface |
| ▪ |
Detector wide range |
: |
190-930nm |
| ▪ |
Operate |
: |
Easy to operate GUI |
| |
|
|
(Graphical User Interface) |
| |
|
: |
Automatic gas box for easy changeover from Air to N2O |
| |
|
: |
Push button ignition |
| |
|
: |
Emergency gas shut-off in case of flame outage |
| ▪ |
Port USB |
: |
4 USB port for Printer, mouse and keyboard |
| ▪ |
Wavelength adjustment |
: |
3 digit motor driven, |
| |
|
|
0 to 1000nm +0.1 nm |
| ▪ |
Reproducibility |
: |
+0.1 nm |
| ▪ |
Resolution |
: |
variable slit - 2Å, 7Å, and 20Å |
| ▪ |
Operating Modes |
: |
|
| |
Absorbance/Emission |
: |
-0.0820 to 3.2000 |
| |
Concentration |
: |
to 5 significant digits |
| |
Integration Period |
: |
0.1 to 99.9 seconds |
| |
Screen Refresh |
: |
0.224, 0.448 or 0.896 seconds |
| |
Recorder Output |
: |
1V/ABS (-0.08 to 3.2V) |
| |
Background Correction |
: |
In-line Deuterium Arc |
| ▪ |
Hollow Cathode Lamps |
: |
|
| |
Dimension |
: |
1.5" OD |
| |
Striking Voltage |
: |
500V |
| |
Lamp Current |
: |
0 to 18 mA average current |
| |
|
: |
(typical current is 1.5-8.0 mA) |
| ▪ |
Burner Assembly: |
|
|
| |
Design |
: |
Polyethylene Pre-mix chamber, |
| |
|
: |
glass impact bead dispersion |
| |
Burner Head |
: |
Titanium; air-acetylene head - 4" x 0.026" single slot |
| |
|
: |
(nitrous oxide head - 2" x 0.019" single slot) |
| |
Adjustments |
: |
Horizontal and Vertical positioning |
| ▪ |
Performance: |
|
|
| |
Average Noise (at 3 ) |
: |
0.0018 ABS (Cu at 324.7nm, 7Å slit, 5 sec. int.) |
| ▪ |
Acessories |
|
|
| 1 |
Hollow Cathode Lamps : As, Cu, Hg, Pb, Ag, Fe, Mn, Cd, Se, Zn |
| 2 |
Standards Solution : @125ml for : As, Cu, Hg, Pb, Ag, Fe, Mn, Cd, Se, Zn |
| 3 |
Air Filter included brackets, 2 brass fitting and spre cartridge |
| 4 |
Flash Arrestor included 2 brass fitting |
| 5 |
Minor AA Spare Kit included Nebulizer, impact bead and other spares |
| 6 |
Combination Batch Hydride Generator for As/Se & Cold Vapor Hg |
| 7 |
Acetylene Pressure Regulator included 2 brass fitting |
| 8 |
Air Pressure Regulator |
| 9 |
Argon Pressure Regulator |
| 10 |
Nitrous Oxide Pressure Regulator |
| 11 |
Nitrous Oxide Burner Head |
| 12 |
Hood and Vemt Kit Stainless Steel 220V |
| 13 |
Oil-less Air Compressor 220V |
